Match! uses the “Intermediate Lorentzian” (IL) function to calculate the profile from given Bragg peak data (2θ, intensity) and an associated FWHM (profile width) value. As the name already suggests, the profile function is something in between a Gaussian and a Lorentzian.

The intensity at each point y_i is calculated from the contributions of all peaks k:

The contribution of a peak k to data point i is calculated as follows:

where

is the raw (profile) intensity at point i contributed by peak k

 is the integrated intensity of peak k

 is the width (“full width at half maximum”) of peak k

 is the scaled difference between the 2θ positions of point i and peak k:

Please note: In the current version of Match!, it is not possible to use profile functions other than intermediate Lorentzian for the profile calculation.
